Status element
The ReadingStatus element contains either an EncodedStatus attribute or an UnencodedStatus attribute.
EncodedStatus attribute
The EncodedStatus attribute represents the binary format for reading status values and is available only on readings that are exported from IEE. It is not used on import.
UnencodedStatus attribute
The UnencodedStatus attribute contains string representations of reading status values. It contains one string value for the source validation status and a list of status names for other necessary status values.
SourceValidation attribute
SourceValidation is an attribute of the UnencodedStatus element. The SourceValidation status refers to the validation code, if any, that is passed from the source of the reading. The value is case sensitive and must be one of the following:
-
Uninitialized
-
Unknown
-
NV (not validated)
-
Warning
-
Accepted
-
ManAccepted
-
Passed
StatusCode elements
Additional status values are supplied as a list of StatusCode elements. Each status code is a simple string name. Status code names can be defined according to the external system and reading status mapping that is created in IEE. IEE maps the status code names to internal IEE statuses upon import.
IEE read status codes (subset)
|
Status Code |
Description |
|---|---|
|
ADDED |
Added Interval (Data Correction) |
|
AGGREGATED |
Aggregated Interval |
|
ALARM |
Alarm |
|
BATTERY |
Battery Error |
|
BACKCAST |
Backcast Data |
|
BACKUP1 |
Backup Meter 1 |
|
BACKUP2 |
Backup Meter 2 |
|
BACKUP3 |
Backup Meter 3 |
|
BACKUP4 |
Backup Meter 4 |
|
BACKUP5 |
Backup Meter 5 |
|
BACKUP6 |
Backup Meter 6 |
|
BACKUP7 |
Backup Meter 7 |
|
BACKUP8 |
Backup Meter 8 |
|
BACKUP9 |
Backup Meter 9 |
|
CHECKMETER |
Check Meter Validation |
|
CHOPPED |
Data Chopped for Conversion |
|
CLOCK |
Clock Error/Real Time Clock Error |
|
CONFIGERROR |
Configuration Error |
|
CRC |
CRC Checksum Error |
|
CUSTOMER |
Customer Issue (customer read, locked gate, not home) |
|
DATA |
Data Issue (long interval, short interval, merged intervals) |
|
DELETED |
Deleted |
|
DELTA |
Delta Overflow |
|
DETECT |
Photo Detect Error |
|
DISCONN |
Battery Disconnected |
|
DST |
Daylight Saving Time Action |
|
DUPLICATE |
Duplicate Read |
|
EDITED |
Interval was Edited |
|
EMITTER |
Photo Emitter Error |
|
EMPTY |
Empty, no data in the database for this interval |
|
EMPTYCONTRIBUTOR |
At least one contributor had empty data |
|
ENERGY |
Energy Type (Register Changed) |
|
EQUIPMENT |
Equipment Issue (broken meter, wrong meter) |
|
EXCLUDED |
Excluded Data |
|
FAILED |
Failed Validation or Bad Read |
|
FORECAST |
Forecast Data |
|
FRONTEND |
Front End Error |
|
HARMONIC |
Harmonic Distortion |
|
HIGHLOWLIMIT |
HighLowUsageCheck Validation |
|
IOBOARD |
IO Board Error |
|
IRREGULAR |
Irregular Interval (Short or Long) |
|
ITOLERANCE |
Interval Tolerance |
|
KVARHCHECK |
KvarhCheck Validation |
|
LEAK |
Gas Leak |
|
LIMIT |
Data Out of High/Low Limits |
|
LOAD |
Load Control |
|
LOCATION |
Premise Issue (Cannot find premise, wrong route, bad address) |
|
LOWBATT |
Low Battery |
|
MALFUNCTION |
Program Malfunction |
|
MANACCEPTED |
Manually Accepted Validation |
|
MEASURE |
Measurement Error |
|
MEMORY |
ROM/RAM Checksum Error/Memory Error/ Self Check Error |
|
MISSING |
Missing Data or Lapse in Data |
|
MODEM |
Modem Error |
|
NV |
Not Validated |
|
OPTIONBOARD |
Option board error |
|
OTHER |
Other |
|
OVERFLOW |
Meter Overflow |
|
OVERLOAD |
Overload Error |
|
PARITY |
Parity Error |
|
PASSED |
Passed Validation, Accepted, or Good Read |
|
PFLIMIT |
PowerFactorLimit Validation |
|
PHASE |
Phase Loss Error |
|
POTENTIAL |
Low Loss Potential |
|
POWER |
Power Outage or Unsafe Power Failure |
|
PRIMARY |
Primary Meter |
|
PULSE |
Pulse Overflow |
|
REPLACED |
Replaced Interval (Data Correction) |
|
REPROG |
Meter Reprogrammed |
|
RESERVEDFAM1 |
Reserved for future use |
|
RESET |
Reset Occurred |
|
RESTORED |
Restored |
|
ROLLOVER |
Meter Rollover |
|
ROTATION |
Reverse Rotation Error |
|
SCALEDUSINGTBU |
Scaled Using TBU |
|
SEDITED |
Status Edited |
|
SPIKE |
SpikeTolerance Validation |
|
SSYNC |
Slave Synch Error |
|
STARTREAD |
Start Register Reading |
|
SYSTEM |
External system that has gotten out of sync |
|
TADJUSTED |
Time Adjusted |
|
TAMPER |
Tampered Interval |
|
TAMPERGENERAL |
Meter has been tampered with (tilt, line cut, meter thrown on lawn) |
|
TEST |
Test Mode |
|
THREAT |
Animal or Human Threat (dog, gun, alligator) |
|
TILT |
Tilt |
|
TIMERESET |
Time Reset Occurred |
|
TOTBILLEDUSAGE |
Total Billed Usage |
|
TOU |
TOU Error |
|
TTOLERANCE |
Time Tolerance |
|
UNPROG |
Unprogrammed Error |
|
USAGELIMIT |
UsageLimit Validation |
|
USAGETOL |
UsageTolerance Validation |
|
WARNING |
Warning in Validation |
|
WATCHDOG |
Watchdog Time-out/Error |
